UT20 Rugged Tablet
UT20 7” Rugged Windows Tablet The fully rugged UT20 windows 10 tablets with a 7-inch screen…
Written quote within one business hour. No obligation, no spam.
Prefer to try it first? Ask about short-term hire.
About the UT20 Rugged Tablet.
The eSurvey UT20 is a 7-inch fully rugged Windows tablet built for professional surveying and GIS fieldwork. Unlike the Android UT12P and UT32, it runs full Windows 10 Enterprise 64-bit, so crews can run desktop survey, CAD and office software directly in the field.
It is IP68-certified and MIL-STD compliant, with a bright 550-nit sunlight-readable screen and a hot-swappable battery so work never stops during a battery change. Thin, light and comfortable one-handed, it suits surveyors and GIS professionals who need Windows compatibility with field-grade durability.
Built to make the job faster.
Full Windows platform
Runs Windows 10 Enterprise 64-bit, so desktop survey, CAD and GIS applications run natively with no Android port required.
Bright sunlight-readable display
A 7 inch 1280 x 800 screen at 550 nits, the brightest in this lineup, stays clear in direct sunlight.
Fully rugged sealed build
IP68-certified and MIL-STD compliant against shock, spills and vibration, surviving a 1.5 m drop onto concrete.
Hot-swappable battery
The replaceable battery can be swapped without powering down, extending fieldwork across multiple packs.
Built-in GNSS
An integrated GNSS chipset tracks GPS, BeiDou, GLONASS and Galileo for 1 to 3 m single-point positioning.
Data-capture ready
An 8 MP autofocus camera plus optional barcode-scanning and RFID-reading support field asset workflows.
The full detail.
Display
- Screen
- 7 inch
- Resolution
- 1280 x 800
- Brightness
- 550 nits
- Touch
- Capacitive
Hardware
- Processor
- Intel Apollo Lake N3350, up to 2.4 GHz
- RAM
- 4 GB
- Storage
- 64 GB eMMC, microSD to 128 GB
- Operating system
- Windows 10 Enterprise 64-bit
Connectivity
- Cellular
- 4G LTE
- Wi-Fi
- 802.11 a/b/g/n/ac
- Bluetooth
- 4.2
- Port
- USB Type-C / USB 3.0
- Built-in GNSS
- GPS, BeiDou, GLONASS, Galileo, 1 to 3 m
Physical & Electrical
- Dimensions
- 207 x 138 x 19.8 mm
- Weight
- 745 g
- Battery
- 7.6 V, 4,050 mAh, hot-swappable
- Working time
- About 4 to 6 hours
- Protection
- IP68, MIL-STD-810G and 461F
- Drop rating
- 1.5 m onto concrete
- Operating temperature
- -20 to +60 degC
Camera & Options
- Rear camera
- 8 MP autofocus with flash
- Front camera
- 2 MP
- Optional
- Barcode scanner, RFID reader
Specifications are sourced from the manufacturer and may vary by configuration or firmware. Full datasheets available on request.
Where it earns its keep.
- 01 Running desktop Windows survey, CAD and GIS software in the field
- 02 Field data collection as an instrument controller
- 03 GIS mapping and asset management
- 04 Barcode and RFID asset workflows
- 05 Construction site management and as-builts
- 06 Utility and public-safety fieldwork
Backed by GeoSurv Africa.
The kit is only half of it. Every instrument we supply is backed by our own service centre and a team that knows the gear.
In-house service centre
Calibration, repair and accuracy testing for most professional brands.
Honest, project-led advice
We match the kit to your accuracy needs and budget, no upselling.
Real local support
Phone, email or WhatsApp a person who actually knows the gear.
Equipment hire available
Cover project peaks or service downtime with short-term hire.
