eTS2 HIGH-EFFICIENCY OPERATION TOTAL STATION The eSurvey eTS2 is a high-precision manual…
Written quote within one business hour. No obligation, no spam.
Prefer to try it first? Ask about short-term hire.
About the eTS2 Total Station.
The eSurvey eTS2 is a high-precision manual total station built as a no-frills, high-efficiency field workhorse. It pairs 2-arc-second angular accuracy with a notably long EDM range, up to 5,000 m to a prism and 1,000 m reflectorless, which suits general land surveying, setting out and topographic work where reliability and reach matter more than interface polish.
A standard USB flash-disk interface lets crews move job data on and off the instrument without proprietary cables, and a 3,100 mAh battery covers a full working day. It is the value-focused entry point of the eTS series.
Built to make the job faster.
Long measurement range
Reaches 5,000 m to a prism and 1,000 m reflectorless, more reach than typical entry-level instruments for long traverses and awkward points.
2-arc-second accuracy
An absolute-encoder reading system delivers 2-arc-second angular accuracy, suitable for most cadastral, engineering and setting-out work.
Fast EDM
Fine measurement in 0.3 seconds and tracking in 0.1 seconds for quick, fluid fieldwork.
Dual-axis compensator
A liquid dual-axis tilt compensator with a 4-arc-minute working range corrects instrument tilt automatically.
Plug-and-play USB
A standard USB flash-disk interface makes exporting measured data fast and cable-free.
All-day battery and big memory
A 3,100 mAh battery runs around 8 hours, with onboard memory for up to 100,000 points.
The full detail.
Angle Measurement
- Reading system
- Absolute encoder
- Accuracy
- 2 arc-seconds
- Display resolution
- 0.1 / 1 / 5 / 10 arc-seconds
Distance Measurement
- Range, prism
- 5,000 m
- Range, reflectorless
- 1,000 m
- Accuracy, prism
- 2 mm + 2 ppm
- Accuracy, reflectorless
- 3 mm + 2 ppm
- Measuring time
- Fine 0.3 s, tracking 0.1 s
Telescope & Optics
- Magnification
- 30x
- Minimum focus
- 1.2 m
- Resolution
- 3 arc-seconds
Display & Software
- Screen
- Dual black and white graphic LCD, 6 lines
- Keyboard
- Alphanumeric, 24 keys per face
- Interface
- USB, Bluetooth
Physical & Electrical
- Dimensions
- 200 x 190 x 330 mm
- Weight
- 5.5 kg
- Battery
- 7.4 V, 3,100 mAh
- Working time
- About 8 hours
- Protection
- IP55
- Operating temperature
- -20 to +60 degC
Other
- Compensator
- Dual-axis liquid, 4 arc-minute range
- Laser plummet
- 1.5 mm at 1.5 m, Class 2
- Memory
- 100,000 points
Specifications are sourced from the manufacturer and may vary by configuration or firmware. Full datasheets available on request.
Where it earns its keep.
- 01 General topographic and detail surveys
- 02 Construction setting out and stakeout
- 03 Cadastral and boundary surveys
- 04 Engineering surveys and traversing
- 05 As-built and control surveys
- 06 Long-range point measurement
